DC Power Supply - 0-30V / 0-6A

Y-0012



DC Power Supply is designed to adjust the output Voltage and Current as fine and coarse.



The Power Supply has a shock proof metal case. Power Supply is delivered with power cable, spare fuses, connection leads and user manual.

Tender Specifications

DC POWER SUPPLY

DC Power Supply should be designed to adjust the output Voltage and Current as fine and coarse. The output voltage and current should displayed independently with 3½ Digit LED Display. There should be over current (CC) and constant voltage (CV) warning LEDs on the Power Supply. The Power Supply should have a shock proof separable case.

TECHNICAL SPECIFICATIONS

Power Supply                :    220 V AC / 50 Hz ± 10 %
Output Voltage                :    0 - 30 V DC, fine and coarse adjustable
Output Current                :    0 - 6 A DC, fine and coarse adjustable
Voltmeter Measurement Range        :     3½ digit / 00,0 - 30,0 V
Ammeter Measurement Range        :     3½ digit / 00,0 A - 6,00 A
Voltage Regulation            :    < %1
Warning Indicators            :     CC : Over Current, CV: Constant Voltage
Case                    :    Metal
