Key Features：

• Built-in Hipot test and PD detector function in one instrument
• Programmable voltage output: 0.1KVac ~ 10KVac
• High accuracy and resolution current meter: 0.01uA ~ 300uA
• PD (Partial Discharge) detection range: 1 pC ~ 2000 pC
• High Voltage Contact Check function (HVCC)
• IEC60747-5-5 and IEC 60270-1 Standard compliant
• Built-in IEC60747-5-5 test methods
• 3 stages of voltage test function
• Digital display for PD test results [pC]
• PD defect occurrence setting for judgment (1~10)
• Graphical editing function
• USB screen capture function
• English and Simplified Chinese/Traditional Chinese operating interface
• Standard USB, LAN, RS-232 & Handler Interface

Model/Opsiyon Seçim Tablosu
