Optimized standard test items(On-Board Charger):

Comply with QC/T 895-2011 standard

Charger Pre-setup

• Charger Input/Output Test
• Charger Line Regulation Test
• Charger Load Regulation Test
• Charger Hold On Adjust Test
• Charger Fin Ramp Shut Down Test
• Charger Fin Ramp Start Up Test
• DSO Setup For 4 Channels
• Charger Cursor Measure Time
• Charger Load Setup
• Charger Over Load Protection Test
• Charger OVP (CC Mode) Test
• Charger OVP (CV Mode) Test
• Charger Peak Current Test
• Charger Ripple & Noise Test
• Charger Short Circuit Protection Test
• Charger Static Test
• Charger Vin Ramp Shut Down Test
• Charger Vin Start Up Test
• Charger Waveform Measure Test
• Charger Waveform Measure Turn On Test
• Charger Waveform Measure Turn Off Test
• Enable Turn On/Off Charger
• CAN Bus Reading Charger

Optimized standard test items(DC-DC Converter):

Comply with GB/T 24347-2009 standard

Charger Pre-setup

• DC-DC Input/Output Test
• DC-DC Line Regulation Test
• DC-DC Load Regulation Test
• DC-DC Hold On Adjust Test
• DSO Setup For 4 Channels
• DC-DC Cursor Measure Time
• DC-DC Over Load Protection Test
• DC-DC Over Voltage Protection Test
• DC-DC Peak Current Test
• DC-DC Ripple & Noise Test
• DC-DC Short Circuit Protection Test
• DC-DC Total Regulation Test
• DC-DC Vin Ramp Shut Down Test
• DC-DC Vin Start Up Test
• DC-DC Waveform Measure Test
• DC-DC Waveform Measure Turn On Test
• DC-DC Waveform Measure Turn Off Test
• Total Efficiency Test
• Enable Turn On/Off DC-DC
• CAN Bus Reading Charger
• CAN Bus Pre-Setup
