Conveyor Belt Training Kit is a 2-axis model designed for training purposes for the conveyors used in factory automation systems.

The control and separation of the materials processed will be processed on the production lines while transferred from one point to another can be formed. Conveyor Belt Training kit is concordant with such a scenario due to its design.

There is input/output control module conforming to control with PLC.

System can be dissembled/assembled and developed for various scenarios. Anodized aluminum sigma profile is used for the structure.

Application software CD for the operation of the system  is provided with the user’s guide of the set.

Technical Specifications :

• Supply Voltage 24V DC 2A (Optional Power Supply Y-0030-A12)
• 3 pcs optical sensors
• 1 pcs capacitive sensor
• 1 pcs inductive sensor
• 2 pcs relay controlled DC motors
• 2 pcs 48 cm linear motion conveyor band
• Movement for two lines X and Y
• 8 inputs /6 outputs PLC control connection
• Input and output points with 2 mm born connectors
• 50x65cm aluminum sigma profile based

Applications :

• Assembling/Installation applications
• Diagnosis and fault repair
• Comments and examination of documentations
• Examination of operating principle of conveyor mechanism
• Connection and control of electronic connection of the mechanical structure
• On-board sensor circuit applications
• Examination of motor control

Your Needs For Appliacations :

• 8 DI / 6DO / 2AI / 1AO PLC Unit
• Power Supply 24V DC 2A
